Electrical Protection: Breakdown voltage up to 3000V. Blocks stray currents to prevent electrical corrosion.
Ample Stock: A stable supply chain and sufficient inventory enable us to fulfill most orders.
Reliable Quality: Compliant with ISO 9001 and REACH standards. The production process is fully traceable.
Flexible MOQ: Low Minimum Order Quantity (MOQ). Supports both small-batch and large-volume orders.
The TFL 6230M/C3VL0241 serves as a direct equivalent to brass-cage insulated bearings of the same specification from leading global brands like SKF and FAG. Its high-capacity mechanical design harmonizes with the 3000V dielectric insulation layer, allowing for seamless installation in existing megawatt-class generators or high-pressure pump drives. Strict quality control prior to delivery ensures long-term operational stability in VFD-controlled rotating machinery.
| SKF | FAG | NTN |
|---|---|---|
| 6230M/C3VL0241 | 6230-M-J20AA-C3 | 7MC3-6230C3 |
TFL is an integrated supplier focused on supplying high-quality electrically insulated bearings for the global industrial sector. Through a refined supply chain system and strict ISO 9001 quality management, we guarantee that every product delivered meets premium standards in both precision and dielectric performance. By offering flexible support with zero MOQ, fast-turnaround logistics, and professional engineering selection advice, TFL is committed to being your trusted partner for optimizing procurement plans and reducing Total Cost of Ownership (TCO).
Machined Brass Cage (M) — High mechanical strength, ideal for severe vibration and dynamic loads.
150mm Large Bore Construction — Engineered for massive industrial drive shafts.
High Dielectric Resistance — 50–200 MΩ, ensuring zero leakage of VFD shaft currents.
The TFL 6230M/C3VL0241 high-voltage insulated bearing is specifically supplied for heavy industries with highly demanding requirements for vibration and mechanical loads. Typical applications include rail traction motors, megawatt-class wind turbine generators, paper-making dryer drum drives, and variable-speed centrifugal pump systems.
TFL 6230M/C3VL0241 electrically insulated deep groove ball bearings can be applied in Alstom or Siemens rail traction motor systems. Operating under frequent track vibrations and high-frequency pulse currents, this model utilizes its high-strength machined brass cage and 3000V dielectric protection to safeguard raceways from both mechanical damage and electrical erosion.
In the wind power sector, TFL 6230M/C3VL0241 is suitable for the main generators of 2.5MW to 5MW wind turbines from brands like Vestas or Goldwind. The fatigue-resistant machined brass cage withstands intense load fluctuations during variable-speed wind operations, while the ceramic coating blocks leak currents and shaft voltages, extending the overall operating life.
For heavy-duty centrifugal feedwater pumps from brands like Sulzer or KSB, TFL 6230M/C3VL0241 provides excellent shaft-end isolation. Under VFD operation, where the equipment must handle constant fluid pulsations and electromagnetic impulses, the machined brass cage combined with the high-voltage insulation layer ensures stable pump operation in humid and heavy-load environments.
*The brands and series mentioned are provided for industry illustration only. Final bearing selection should be confirmed through verification of dimensions, clearance class, insulation type, and operating conditions. For selection assistance or technical consultation, please contact the TFL engineering team for support.
Discover more related products for your needs. Check out our hot-selling bearing models that serve as trusted alternatives to major brands like SKF and FAG—offering the same performance with greater value.
