VFD Motor Ready: Designed for VFD motors and inverter-driven motor bearing replacement applications.
Interchangeable: Compatible with SKF/FAG models for a perfect replacement.
Reliable Quality: Compliant with ISO 9001 and REACH standards. The production process is fully traceable.
Fast Sourcing Support: Common insulated bearing models available for urgent motor repair and replacement needs.
TFL 6236M/C3VL2071 has an interchange basis with SKF, FAG, and other insulated bearing types through its dimensions, C3 clearance, and VL2071 inner-ring insulation structure. VL2071 indicates an inner-ring insulation design mainly used for applications requiring isolation of the shaft-side current path.
Replacement should not be determined only from the base designation 6236M. Buyers should verify the complete suffix, clearance class, cage type, insulation location, and operating conditions. TFL can assist with direct replacement review based on the original bearing designation, photos, and application information.
| SKF | FAG |
|---|---|
| 6236M/C3VL2071 | 6236-M-J20C-C3 |
TFL focuses on electrically insulated bearing supply, providing model verification, interchange review, and delivery support for industrial buyers, motor repair teams, and distributors. For VL2071 inner-ring insulated bearings such as 6236M/C3VL2071, we verify dimensions, C3 clearance, insulation location, cage type, and complete original designations to reduce selection errors.
TFL supports No MOQ, small maintenance orders, bulk purchasing, OEM/ODM, and consolidated shipments, helping customers meet electrical insulation requirements while reducing sourcing costs.
VL2071 inner-ring insulation — alumina ceramic coating applied to the inner ring for shaft-side electrical isolation.
Brass cage design — suitable for continuous-duty industrial motor and generator applications.
Inner-ring insulation configuration — different from VL0241 outer-ring insulated bearings.
TFL 6236M/C3VL2071 electrically insulated deep groove ball bearing is suitable for large inverter motors, industrial motors, generators, and other electric drive systems where shaft current protection is required.
The VL2071 inner-ring insulation structure helps isolate shaft-side current paths and reduce electrical erosion risk. The C3 clearance and brass cage support continuous operation, temperature variation, and long-term load conditions.
Final selection should be verified by original dimensions, insulation location, clearance, fits, load, and speed.
TFL 6236M/C3VL2071 can be considered for large inverter motor equipment types, including Siemens 1LE0001 and ABB M3BP series.
Inverter-driven operation may generate shaft currents, allowing the bearing to become part of the current path and causing electrical erosion. The VL2071 inner-ring alumina ceramic insulation helps isolate shaft-side current paths and is suitable for replacement review where inner-ring insulation and C3 clearance are specified.
TFL 6236M/C3VL2071 can be considered for bearing positions in industrial compressors and large pump motors, including centrifugal compressors, circulation pumps, and water treatment drive systems.
These systems often operate continuously under variable-frequency control, high loads, and complex grounding conditions where shaft current issues may occur. The VL2071 inner-ring insulation structure helps reduce bearing damage risks caused by electrical current while maintaining standard dimensional interchangeability.
TFL electrically insulated bearings such as 6236M/C3VL2071 can be considered for generator bearing positions in wind turbines, including equipment types from Vestas, Goldwind, and Siemens Gamesa.
Wind turbine generators operate under variable speed, vibration, humidity, and fluctuating load conditions, making shaft-current protection an important consideration during bearing selection. The VL2071 inner-ring insulation of 6236M/C3VL2071 can be considered for wind turbine generator bearing replacement review, but the original equipment must be confirmed to require inner-ring rather than VL0241 outer-ring insulation.
*The brands and series mentioned are provided for industry illustration only. Final bearing selection should be confirmed through verification of dimensions, clearance class, insulation type, and operating conditions. For selection assistance or technical consultation, please contact the TFL engineering team for support.
